Model No. |
U100 |
|
|
Image Sensor |
Sensor |
1/2.7"HD color CMOS |
|
Effective Pixel |
2.1 Megapixel |
|
|
Minimum Scene illumination |
5Lux at F2.0 |
|
|
White Balance |
AUTO |
|
|
Gain Control |
AUTO |
|
|
Back-light compensation |
N/A |
|
|
Electronic Shutter |
N/A |
|
|
S/N Ratio |
>50db |
|
|
Lens |
Focus |
6.0mm |
|
Iris |
N/A |
|
|
Zoom |
Fixed Lens |
|
|
HOV |
56.2° |
|
|
Video Output |
USB2.0 |
|
|
Video format |
1080p29.720p31 |
|
|
Communication |
RS232,usb |
|
|
PTZ Control Protocol |
VISCA |
|
|
Baud Rate |
9600bps |
|
|
Patrol tours |
N/A |
|
|
Preset |
32 |
|
|
Speed Matching Function |
N/A |
|
|
Image Auto Flip |
Support |
|
|
Pan Speed |
6-27°/S |
|
|
Tilt Speed |
6-27°/S |
|
|
Pan Rotation Angle |
0-359° |
|
|
Tilt Rotation Angle |
90°(up), 45°(down) |
|
|
Auto Pan Scan |
/ |
|
|
Boundary Scan |
0-359 degree |
|
|
Remoter Control |
IR Wireless remote control P/T/Z |
|
|
Power |
DC5V,1A |
|
|
Operation Temperature |
0-50℃ |
|
|
Environmental humidity |
0-95%RH |
|
|
Length X width X high |
115mm×116mm×132mm |
|
|
Weight |
330g |
|
