HD380-U30-K2 USB 3.0 Video PTZ Camera
HD380-U30-K2 USB 3.0 Video PTZ Camera
Liên Hệ

HD380-U30-K2 USB 3.0 Video PTZ Camera

2.1 Megapixel Full HD Camera experience 1080i@60 vivid images, equipped with 10x optical zoom lens, enhancing your video conferencing, distance learning, training meeting, courtrooms or remote medical with natural and smooth video images. Support USB Interface which is easy to installation and transfer high-quality video streaming.


Features:
 Private Tooling design High Definition PTZ camera
 Fast and smooth video handling
 Power ON-OFF switch
 Work & Standby LED indicator
 Speed Match
 Auto/Manual focus/brightness/WB
 RS-232C/VISCA Protocol
 Lens/Dome OSD menu
 Boundary scanning
 Standby & wakeup status
 Swap video format button
 USB Video output

Performance:
 1920x1080 pixels progressive @30fps
 10x optical zoom
 F=5-50 mm F2.0-2.8
 HOV 51.8° ~5.86° degree
 1/3" CMOS Pan ±175°
 Tilt ±120°
 64 preset positions
 4 cruise lines
 DC 12V, 2A

Dimension:
 L 124mm x W 120mm x H145mm
 220x175x220mm (Package)
 N. Weight: 1.4kgs
 G. Weight: 1.7kgs

Installation:
 Desktop
 Ceiling mount
 Standard Tripod accessory

12 Tháng
: Đang Có Hàng

Model

HD380-USB-K2


SenSor

Sensor

1/3” CMOS, 2.1 M compatible

Minimum Scene lllumination

0.1 Lux

White Balance

AUTO/Manual

Gain Control

AUTO

Back-light compensation

ON/OFF

Electronic shutter

1/30~1/10000S

S/N Ratio

>50db

Lens

Focus

AUTO

Iris

AUTO/Manual

Zoom

10x Optical Zoom

1/3.6model   f=5-50 mm

Video Output

USB Interface

Video format

1080P@30,1080P@25,1080P@24,1080i@60, 1080i@50,720P@60,720P@50

Control Decoder

EIA/RS-485

Communication

EIA/RS-232(Bidirectional)

PTZ Control Protocol

VISCA,PELCO-P,PELCO-D

Baud Rate

9600/38400 bps

Patrol tours

4

Preset

64

Save status after Power off

Support

Speed Matching Function

Support

OSD Menu

Support

Image Auto Flip

Support

Pan Speed

0-100 degrees/s

Tilt Speed

0-80 degrees/s

Pan Rotation Angle

359degrees

Tilt Rotation Angle

240degrees

Auto Pan Scan

Support

Boundary Scan

0-359degrees(Programmable)

Remoter Control

IR Wireless remote control P/T/Z

Power

DC12V ±10% 1.2A

Operation Temperature

-10℃~60℃

Environmental humidity

0-95%RH(non-condensation)

Length X width X high

124x120x145mm/220x175x220mm(NET/PACKAGE)

Weight

800g/1300g(NET/PACKAGE)
