Model Number |
C368-18 |
|
|
Image Sensor |
Sensor |
SONY FCB-EX48EP 1/4-type EXview HAD CCD |
|
Signal System |
PAL/NTSC |
|
|
Illumination |
1.0Lux/F1.4 |
|
|
White Balance |
Auto/Manual |
|
|
Gain Control |
Auto |
|
|
Back-light |
On /Off |
|
|
E-Shutter |
1 - 1/100,000s |
|
|
Horizontal |
550 TVL |
|
|
S/N Ratio |
>50db |
|
|
Lens |
Focus |
f=4.1-73.8 F1.4 -3.0 |
|
Iris |
Auto/Manual |
|
|
Zoom |
18 Optical X 12 Digital Zoom |
|
|
Video Output |
AV, S-VIDEO, USB Output (Optional) |
|
|
Control Decoder |
Built-in decoder |
|
|
Communication |
EIA/RS422, EIA/RS232(Bidirectional) |
|
|
PTZ Control Protocol |
VISCA, PELCO-P, PELCO-D(optional) |
|
|
Baud Rate |
4800/9600bps |
|
|
Patrol Lines |
4 Patrol Lines |
|
|
Preset Position |
64 Preset Position |
|
|
Power-off Protection |
Saved scanning or patrol line settings Automatically Before power off |
|
|
Speed Matching |
Slow down camera Pan/Tilt movement speed while camera zooming in |
|
|
OSD Menu |
To change parameters of camera or camera module from OSD Menu |
|
|
Image Auto Flip |
Image Auto Flip |
|
|
Pan Speed |
1-280 degree per second |
|
|
Tilt Speed |
1-100 degree per second |
|
|
Pan Rotation Angle |
360 degree continuously |
|
|
Tilt Rotation Angle |
240 degree |
|
|
Auto Pan Scan |
Support auto pan scanning |
|
|
Boundary Scan |
0-359 degree(programmable) |
|
|
Remoter Control |
IR wireless remote controller P/T/Z |
|
|
Power Supply |
DC12V±10%, 1.2A |
|
|
Working Temperature |
0-50℃ |
|
|
Environment Humidity |
0-95%RH |
|
|
Size(LxWxH) |
124X120X145mm |
|
|
Weight |
1300g |
|
