Model |
C360-12 |
|
|
Image Sensor |
CCD |
1/4" Interline Transfer CCD |
|
Minimum Scene Illumination |
0.2Lux at F1.6 |
|
|
White Balance |
AUTO/Manual |
|
|
Gain Control |
Auto |
|
|
Back-light Compensation |
On/Off |
|
|
Electronic shutter |
1/50-1/120,000s |
|
|
Horizontal resolution |
560 TVL |
|
|
S/N Ratio |
> 50dB |
|
|
Lens |
Focus |
AUTO |
|
Iris |
AUTO/Manual |
|
|
Zoom |
12 Optical X 16 Digital Zoom |
|
|
f=3.9-46 mm, F1.67-1.88 |
||
|
Video Output |
VIDEO VBS 1.0Vpp at 75ohm; |
|
|
S-VIDEO(Only for SONY Camera block) |
||
|
Communication |
EIA/RS-422 |
|
|
EIA/RS-232(Bidirectional) |
||
|
Baud Rate |
2400/4800/9600 bps |
|
|
Patrol tours |
4 |
|
|
Pattern tours |
4 |
|
|
Preset |
64 |
|
|
Privacy Mask Zone |
4 |
|
|
Power On Active |
Auto pan scan or Patrol(Programmable) |
|
|
Speed Matching Function |
Support |
|
|
OSD Menu |
Support |
|
|
Image Auto Flip |
Support |
|
|
Pan Speed |
0-280 degrees/s |
|
|
Tilt Speed |
0-100 degrees/s |
|
|
Pan rotation angle |
360 degrees continuously |
|
|
Tilt rotation angle |
180 degrees |
|
|
Auto Pan Scan |
Support |
|
|
Boundary Scan |
0-359 degrees(programmable) |
|
|
Remoter Control |
IR Wireless remote control P/T/Z(10M) |
|
|
Power |
DC 12V+-10%; 1.2A |
|
|
Temperature and humidity |
0°-60℃, 0-95% RH(non-condensation) |
|
