Model |
12X |
20X |
|
Camera Parameter |
||
|
Optical Zoom |
12X,f=3.9~46.1mm |
20X,f=4.7~94mm |
|
Sensor |
1/2.8 inch high quality HD CMOS sensor |
|
|
Effective Pixels Video Format |
16: 9 2.07 megapixel |
|
|
1080P60/50/30/25/59.94/29.97;1080I60/50/59.94;720P60/50/30/25/59.94/29.97 |
||
|
View Angle |
6.3°(tele)--72.5°(wide) |
3.3°(tele)--54.7°(wide) |
|
Digital Zoom |
10X |
|
|
Minimum Illumination |
0.5Lux (F1.8,AGC ON) |
|
|
DNR |
2D & 3D DNR |
|
|
White Balance |
Auto / Manual/ One Push/ 3000K/ 4000K/5000K/6500K |
|
|
Focus |
Auto/Manual |
|
|
Aperture |
Auto/Manual |
|
|
Electronic Shutter |
Auto/Manual |
|
|
BLC |
ON/OFF |
|
|
WDR |
OFF/ Dynamic level adjustment |
|
|
Video Adjustment |
Brightness,Color,Saturation,Contrast,Sharpness,B/W mode,Gamma curve |
|
|
SNR |
>55dB |
|
|
Input/Output Interface |
||
|
Video Interfaces |
HDMI,3G-SDI,LAN,RS232(Ring through RS232 port),RS485,A-IN,A-OUT,Biult-in pick-up |
|
|
Image Code Stream |
Dual stream output |
|
|
Video Compression Format |
H.264,H.265 |
|
|
Control Protocol |
VISCA/Pelco-D/Pelco-P; Baud Rate: 115200/9600/4800/2400bps |
|
|
Audio Input Interface |
Double track 3.5mm linear input; |
|
|
Audio Compression Format |
AAC/MP3 Audio compression |
|
|
HD IP Interface |
100M IP port(100BASE-TX); 5G WiFi (optional),Support Visca protocol control through IP port. |
|
|
Network Protocol |
RTSP/RTMP,ONVIF,GBT28181 |
|
|
Power Interface |
HEC3800 outlet (DC12V) |
|
|
PTZ Parameter |
||
|
Pan Rotation |
±170° |
|
|
Tilt Rotation |
-30°~+90° |
|
|
Pan Control Speed |
0.1 -100°/sec |
|
|
Tilt Control Speed |
0.1-45°/sec |
|
|
Preset Speed |
Pan: 100°/sec,Tilt: 40°/sec |
|
|
Preset Number |
255 presets (10 presets by remote controller) |
|
|
Other Parameter |
||
|
Supply Adapter |
AC110V-AC220V to DC12V/1.5A |
|
|
Input Voltage |
DC12V±10% |
|
|
Input Current |
1A(Max) |
|
|
Consumption |
12W (Max) |
|
|
Store Temperature |
-10℃~+60℃ |
|
|
Store Humidity |
20% - 95% |
|
|
Working Temperature |
-10℃~+50℃ |
|
|
Dimension |
258mmX172mmX168mm |
|
|
Weight |
1.54KG |
|
|
Remote Operation (IP) |
Remote Upgrade,Reboot and Reset |
|
|
Accessory |
power supply,RS232 control cable,remoter,manual,warranty card |
|
