HD8820-SN6300 DVI/HDMI PTZ Video Camera

3.27 Megapixel Full HD Camera experience experience 1080p@30 vivid images, equipped with SN6300 which is 20x optical zoom lens, enhancing your video conferencing, distance learning, training meeting or courtrooms with natural and smooth video images. The DVI Video output interface is suited for Web conferencing software or codec which provide high-quality video display.


Features:
 DVI Interface
 Private Tooling design High Definition PTZ camera
 Fast and smooth video handling
 Power ON-OFF switch
 Work & Standby LED indicator
 Speed Match
 Auto/Manual focus/brightness/WB
 RS-232C/VISCA Protocol
 Lens/Dome OSD
 Boundary scanning
 Standby & wakeup status
 Swap video format key

Performance:
 1920x1080 pixels progressive @30fps
 20x optical, 12x digital zoom
 F=4.7-94 mm F1.6-3.5
 HOV 55.4 degree
 1/2.8” Type Exmor CMOS 3.27 Mega Pixel Sensor
 Pan ±177.5 degree
 Tilt +90 degree, -45degree
 64 preset positions
 4 cruise lines
 DC 12V, 2A

Dimension:
 L 250mm x W 140mm x H154mm
 N. Weight: 2.6kgs
 G. Weight: 4.8kgs

Installation:
 Desktop
 Ceiling mount
 Standard Tripod accessory

12 Tháng
: Đang Có Hàng

 Model No.

HD8820-SN6300

Sensor

Image Sensor

1/2.8" Type Exmor CMOS

Effective Pix

3.27 Megapixel

Min. Illumination

0.5Lux at F1.6

White balance

Auto/Manual

Gain control

Auto/Manual

Backlight compensation

On/Off

Shutter speed

1/1 - 1/10,000S

S/N ratio

>50db

Lens

Focus

f=4.7-94mm  F1.6-3.5

Iris

Auto/Manual

Lens

20 Optical x 12 digital zoom

Horizontal view angle

55.4

Video output

DVI HDMI

Signal system

1080P@30,1080P@25,
1080i@60,1080i@50,
720P@60,720P@50 ,720P@30, 720P@25 ,PAL ,NTSC

Control terminal

EIA/RS232C,EIA/RS485(Bidirectional)

Control Protocol

VISCA,PELCO-D

baud rate

9600/38400bps

patrol line

4 cruise sequence

preset position

64 preset positions

Speed Match

Pan/Tilt movement speed depends on camera module zoom in/out

OSD Menu

Access to OSD Menu and adjust camera module parameters

Image auto flp

Support Horizontal/Vertical image flip

Pan movement speed

1-200°/Second

Tilt movement speed

1-150°/Second

Pan movement range

Pan: 0-355°

Tilt movement range

Up: 45°, Down: 45°

Pan scanning automatically

Support Pan scanning automatically

Boundary scanning

0-355°(programmable)

Remote controller

IR Wireless Remote controller P/T/Z

Power supply

DC12V,2A

Work Temperature

0-50℃

Humidity

0-95%RH

LxWxH

250mm x 140mm x 154mm

Weight

1380g
