HD8820-DSYC-SN6300 HD-SDI DSYC PTZ Camera

3.27 Megapixel Full HD Camera experience 1080i@60 vivid images, equipped with 20x optical zoom lens, enhancing your video conferencing, distance learning, training meeting or courtrooms with natural and smooth video images. The HD-SDI, YPbPr, CVBS Video output available at model HD 8820-DSY multi-interface only, and DVI-I connector is suited for DVI-D analog component which provide high-quality video display.


Features:
 Private Tooling design High Definition PTZ camera
 Fast and smooth video handling
 Power ON-OFF switch
 Work & Standby LED indicator
 Speed Match
 Auto/Manual focus/brightness/WB
 RS-232C/VISCA Protocol
 Lens/Dome OSD
 Boundary scanning
 Standby & wakeup status
 Swap video format
 DVI/HDMI Video output

Performance:
 1920x1080 pixels progressive @30fps
 20x optical, 12x digital zoom
 F=4.7-94mm F1.6-3.5
 HOV 55.4 degree
 1/2.8” Type Exmor CMOS 3.27 Mega Pixel Sensor
 Pan ±177.5 degree
 Tilt +90 degree, -45degree
 64 preset positions
 4 cruise lines
 DC 12V, 2A

Dimension:
 L 250mm x W 140mm x H154mm
 N. Weight: 2.6kgs
 G. Weight: 4.8kgs

Installation:
 Desktop
 Ceiling mount
 Standard Tripod accessory
12 Tháng
: Đang Có Hàng

 Model No.

HD8820-DSYC-SN6300

Sensor

Image Sensor

1/2.8" Type Exmor CMOS

Effective Pix

3.27 Megapixel

Min. Illumination

0.5 Lux at F1.6

White balance

Auto/Manual

Gain control

Auto/Manual

Backlight compensation

On/Off

Shutter speed

1/1 - 1/10,000S

S/N ratio

>50db

Lens

Focus

f=4.7-94mm  F1.6-3.5

Iris

Auto/Manual

Lens

20 Optical x 12 Digital Zoom

Horizontal view angle

55.4

Video output

HDMI, HD-SDI, DVI , YPbPr, CVBS

Signal system

1080P@30,1080P@25,
1080i@60,1080i@50,
720P@60,720P@50 ,720P@30, 720P@25 ,PAL ,NTSC

Control terminal

EIA/RS232C,EIA/RS485(Bidirectional)

Control Protocol

VISCA,PELCO-D

baud rate

9600/38400bps

patrol line

4 cruise sequence

preset position

64 preset positions

Speed Match

Pan/Tilt movement speed depends on camera module zoom in/out

OSD Menu

Access to OSD Menu and adjust camera module parameters

Image auto flp

Support Horizontal/Vertical image flip

Pan movement speed

1-200°/Second

Tilt movement speed

1-150°/Second

Pan movement range

Pan: 0-355°

Tilt movement range

Up: 90°, Down: 45°

Pan scanning automatically

Support Pan scanning automatically

Boundary scanning

0-355°(programmable)

Remote controller

IR Wireless Remote controller P/T/Z

Power supply

DC12V,2A

Work Temperature

0-50℃

Humidity

0-95%RH

LxWxH

250mm x 140mm x 154mm

Weight

1380g
